- CATIA: V6R2013X
- Duration: 105 minutes
- Targeted audience: CATIA users
-
Recommended Preparation course:
- CATIA V5 Fundamentals or CATIA V6 Mechanical Design Fundamentals
- Exam description: the exam includes several problem sets focusing on modeling and modification of basic, intermediate and advanced parts. It includes also some multiple choice questions on basic Drafting principles
-
Topics covered:
- Sketch features, tools & relations
- Basic and dress-up features such as pads, pockets, shafts, fillets, chamfers, patterns...
- Analysis and modification of the geometry, sketch offset, materials, measures, mass properties…
- Drafting questions on views, dimensions, title blocks,
