DESCRIPTION
This learning path provides you with a guided and systematic approach to learn about the NC Prismatic Machine Programmer Role. In
this learning path, you will learn how to create NC programs to perform machining activity. You will learn to define machining operations,
compute and replay the tool path, and generate the NC code output for programs. Additionally, you will learn how to analyze the material
removal during machining to generate clash free tool path and simulate NC machine using the NC code.
this learning path, you will learn how to create NC programs to perform machining activity. You will learn to define machining operations,
compute and replay the tool path, and generate the NC code output for programs. Additionally, you will learn how to analyze the material
removal during machining to generate clash free tool path and simulate NC machine using the NC code.
OBJECTIVES
Upon completion of this learning path, you will be able to:
- Prepare the machining infrastructure
- Define milling tool assemblies
- Define operation and replay tool path
- Simulate NC machine using tool path and NC Code
- Generate NC output
Version
3DEXPERIENCE R2021x
Duration
23 hours
Level
Fundamental
Type
Role
Author
DS Portfolio
Language
English
Knowledge Prerequisites
Software Prerequisites
3DEXPERIENCE ROLES: Collaborative Business Innovator, NC Prismatic Machine Programmer, and NC
Machine Code Validation Specialist
Machine Code Validation Specialist
SAmple certification test :
3DEXPERIENCE NC Prismatic Machine Programmer
