Stamping Die Engineer – Industrial Sheet Metal Stamping Die Design

Stamping Die Engineer – Industrial Sheet Metal Stamping Die Design Service

Starting Price:
$8,500 (Base Package — advanced multi-stage tooling quoted separately)

Short Description

Professional sheet metal stamping die engineering from concept through detailed tooling design. This service integrates spring-back simulation results, die compensation, surface morphing, and best-practice die face creation to accelerate production, reduce rework, and eliminate the need for physical prototypes.

Full Description

The Stamping Die Engineer for Industrial Equipment service provides a complete engineering workflow for sheet metal stamping die design, from conceptual planning to fully detailed tooling.

This service dramatically increases productivity by guiding users through:

• Concept method planning
• Die face creation
• Tool surface development
• Spring-back compensation
• Integration of simulation results
• High-quality morphed surface generation

Our engineering team uses advanced modeling and simulation to connect forming analysis, spring-back predictions, and compensation surfaces directly to die design. This eliminates design duplication, increases accuracy, and reduces the need for costly trial-and-error physical prototypes.

This service is also fully optimized for 3D design, enabling concurrent engineering, design-for-manufacturing collaboration, and multi-disciplinary integration (mechanical, thermal, fluid-related deformation, etc.).

Key Capabilities

Concept-to-Detail Die Design

• Concept method planning for stamping operations
• Die face development based on industry best practices
• High-quality tool surfaces generated from simulation insights

Spring-Back & Compensation Engineering

• Integration of simulation results for forming and spring-back
• Global and localized deformation features
• Automated tool compensation workflows
• Morphed surfaces with preserved topology

Advanced Sheet Metal Engineering

• Rapid feasibility evaluation
• Compensation of complex deformation without redesigning the part
• Direct connection between product shape and simulation feedback

3DEXPERIENCE Integration

• Seamless connection between concept and detail design
• Team-based concurrent engineering
• Simulation data integration (mechanical, fluid, thermal)

Benefits

• Higher productivity with guided wizards and specialized features
• Reduced cost by minimizing physical die trials and prototypes
• Accurate early validation using simulation-driven die face design
• Automated compensation for deformation and spring-back
• High quality surfaces for manufacturable tooling
• Intuitive and process-oriented workflow
• Improved DFM collaboration across engineering teams
• Faster lead times from concept to production-ready tooling

What’s Included — Base Package ($8,500)

• Concept die planning for one stamped metal component
• Die face development using industry best practices
• Integration of forming & spring-back simulation (client-provided or optional add-on)
• High-quality surface generation and morphing
• Tool compensation workflow with global + local deformation control
• Deliverables in STEP, IGES, CATPart, or client-requested formats
• Technical review and 2 revision cycles
• DFM evaluation & recommendations

Advanced Options (Custom Quote)

• Multi-stage die system engineering (progressive, transfer, tandem)
• Full simulation package: forming, spring-back, heat deformation
• Large assembly die design
• Tryout reduction & digital validation workflows
• Onsite or remote engineering training
