Industrial Robotics Cell Design and Engineering Service

Industrial Robotics Cell Design & Engineering Service

Starting Price: $12,000

Turnkey engineering design for complete robotic cells, including safety, mechanical layout, electrical design, and PLC/HMI integration.

What’s Included

• Mechanical & Layout Design
• 2D layout and 3D cell model
• Robot base placement and reach envelope plotting
• EOAT (End of Arm Tooling) design and selection
• Electrical Engineering
• UL-508A compliant control panel design
• Integration of servo drives, VFDs, PLC racks
• Safety circuits (Category 3/4, SIL2/SIL3)
• Safety Compliance
• Risk assessment (ISO 12100, ISO 10218)
• Guarding design: fencing, light curtains, scanners
• Interlock design
• Control System Design
• PLC logic for robot interactions
• SCADA/HMI design (WinCC Unified, FT View, Ignition)
• Recipe-based system design for different SKUs
• Documentation Package
• Mechanical drawings
• Electrical schematics
• Safety compliance documentation
• Installation instructions
